This M12/M8 IP68 connector series is a high-performance waterproof circular connector with straight floating female head design, offering 3/4/5/8/12/17 pin configurations and optional M8/M12 specifications. Adopting nickel-plated brass housing and PPS insulation, it features IP68 waterproof performance in locked state, 75dB shielding at 10MHz and 96hr salt spray resistance. Suitable for industrial automation, outdoor equipment and smart manufacturing, it ensures stable electrical transmission in harsh environments and all materials comply with RoHS requirements.
The connector achieves IP68 protection grade in the locked state, effectively preventing water and dust intrusion even in deep water or dusty industrial environments, fully meeting the high sealing requirements of outdoor and industrial field equipment.
It has a professional shielding structure with 75dB shielding performance at 10MHz, which can effectively resist external electromagnetic interference, ensure stable transmission of industrial control signals, and avoid signal distortion caused by interference.
Providing M8/M12 dual specifications and 3/4/5/8/12/17 pin flexible configurations, matching different wire gauges and rated currents, it can meet the diverse power and signal transmission needs of various industrial automation equipment.
Working stably in -40℃~125℃ extreme temperature range and ≤95% humidity (60℃), it resists 15g vibration (10Hz~2000Hz) and passes 96hr salt spray corrosion test, adapting to various harsh industrial working conditions.
Adopting gold-plated tin bronze contacts with maximum contact resistance ≤10mΩ and insulation resistance ≥100MΩ, nickel-plated brass housing enhances corrosion resistance, ensuring low-loss and long-term stable electrical transmission.
With straight/elbow joint options, quick-plug/thread/quick-lock tightening methods and customizable wire length/color, the floating female head design compensates for installation errors, making on-site assembly more convenient and efficient.
Parameters | Specifications |
Operating Temperature | -55°C~125°C |
Humidity(max) | <=95%[at 60°C/140°F] |
Salt Spray Corrosion | 96hr |
P op(max) | 60 bar(870psi) |
Mating Cycles | 5000+ times |
Contact Material | Tin Bronze Plated Gold |
Housing Material | Nickle Plated Brass |
Insulator Material | PPS Black |
Other Shell Material | Nickle Plated Brass |
Shock Resistance | 100g[6ms] |
Applied to PLC, servo motors, sensors and actuators in industrial automation lines, 3/4/5 pin M12/M8 connectors realize stable signal and power transmission, with IP68 waterproof adapting to the dusty and humid industrial workshop environment.
Used in outdoor monitoring, street lamp control, smart city and Internet of Things equipment, the IP68 waterproof and high/low temperature resistance ensure the normal operation of equipment in rain, snow and extreme temperature outdoor environments.
Served as a connector for new energy vehicle auxiliary equipment, agricultural machinery and engineering machinery, it resists vibration and salt spray corrosion, adapting to the harsh working environment of vehicles and mechanical equipment.
Applicable to aerospace ground testing equipment and industrial precision detection instruments, the excellent shielding performance and low contact resistance ensure the accuracy and stability of test signal transmission.
Used in marine detection, coastal monitoring and aquaculture equipment, it passes 96hr salt spray corrosion test and has IP68 waterproof performance, effectively resisting seawater corrosion and humid marine environment.
Applied to outdoor medical emergency equipment and industrial laboratory detection equipment, the reliable sealing and environmental adaptability ensure the stable operation of equipment in various complex working conditions.
A: It reaches IP68 in the locked state; you need to ensure the connector is fully locked according to the specified tightening method during use, and avoid artificial damage to the sealing structure to maintain the waterproof performance.
A: It has 3/4/5/8/12/17 pin configurations, 3/4/5 pin with 4A rated current, 8 pin 2A, 12/17 pin 1.5A, matching different wire gauges to meet diverse industrial equipment needs.
A: Yes, it supports customization of wire length (0.1/1/10m etc.), wire color (black/white/grey/blue/yellow), joint type (straight/elbow) and tightening method for on-site equipment matching.
A: It has 75dB shielding at 10MHz, which can effectively resist external electromagnetic interference in industrial control systems, prevent signal distortion of sensors and PLC, and ensure the stable operation of the automation line.
A: It works in -40℃~125℃, resists 15g vibration and 96hr salt spray corrosion, adapts to ≤95% humidity, and is suitable for dusty industrial workshops, outdoor extreme temperatures, marine salt spray and other harsh environments.
