TGC.0H.TYPEC31.X1NM4GS52
QM (QUANMA)
| Quantity: | |
|---|---|
Developed on the mature flat push-pull product platform, TGC.0H.TYPEC31.X1NM4GS52 optimizes internal sealing and shielding structure compared with conventional circular Type-C connectors. The embedded standard Type-C female core realizes synchronous high-speed data and power delivery without extra intermediate adapter accessories. Relying on composite seal construction of silicone cushion plus epoxy encapsulation, the product gains full IP68 dustproof and waterproof rating after complete mating while bearing up to 60bar external hydraulic and ambient pressure. Its full-circle shielding framework effectively suppresses external electromagnetic radiation disturbance and internal signal overflow. Thanks to alloy shell and gold-plated phosphor bronze contact terminals, the connector stands extreme temperature fluctuation, salt fog erosion, mechanical vibration and impact, fitting long-term stable deployment in outdoor, underwater, shipborne and industrial harsh application conditions.
Adopting genuine standard USB3.1 Type-C female core inside the housing, the connector supports high-bandwidth digital data transmission and steady 3A rated current power supply, realizing one-line dual-purpose of signal and electricity. This integrated layout simplifies internal wiring design of finished equipment and matches the lightweight miniaturization development trend of current intelligent precision hardware.
Compound sealing formed by customized silicone rubber washer and transparent epoxy filling eliminates internal gap after mating to achieve IP68 ingress protection under fully locked state. Finished product passes strict hydraulic pressure testing to withstand 60bar (870psi) maximum ambient pressure, well suited for deep-water subsea equipment and high-pressure enclosed operating environments with persistent liquid immersion.
Features professional shielding structure with 75dB shielding at 10MHz and 40dB at 1GHz, effectively resisting electromagnetic interference and signal leakage, which meets the high anti-interference requirements of security and defense equipment signal transmission.
Original flat slim push-pull mechanical layout gets rid of large radial space waste of traditional round connectors, remarkably saving installation space inside compact equipment. Quick push-pull lock design enables convenient repeated plugging and unplugging for field maintenance and equipment debugging works.
The connector keeps stable electrical performance ranging from -55°C to 125°C, works reliably under 60°C and ≤95% relative humidity circumstance. It can withstand 10Hz~2000Hz sweeping vibration of 15g and 100g instantaneous impact with 6ms duration, and completes continuous 96-hour neutral salt spray aging test to cope with coastal and open-air corrosive surroundings.
Blackened sandblasting anodized aluminum alloy shell pairs phosphor bronze contact terminals with immersion gold treatment to improve corrosion resistance and conductive stability of contact points. Its effective plugging cycle hits over 5000 times, surpassing mainstream industry average index and cutting later equipment maintenance cost and part replacement frequency.
Parameters | Specifications |
Operating Temperature | -40°C~125°C |
Humidity(max) | <=95%[at 60°C/140°F] |
Salt Spray Corrosion | 96hr |
P op(max) | 60 bar(870psi) |
Mating Cycles | 5000+ times |
Contact Material | Phosphor Bronze, Gold Immersion |
Housing Material | Aluminum Alloy, Sandblasted & Anodized |
Insulator Material | FR-4 |
Other Shell Material | Aluminum Alloy, Sandblasted & Anodized |
Pin Configuration | USB 3.1TYPE-C |
Shock Resistance | 100g[6ms] |
Rated Current | 3A |
Rated Voltage | 100V AC |
Insulator Resistance | >=100mΩ[at 500V DC] |
IP Rate | IP68(FullyLocked) |
This connector is configured for portable law enforcement instruments, anti-drone countermeasure modules, field security communication terminals and mobile monitoring cameras. Its slim flat outline reduces internal cabinet occupation, built-in EMC shielding avoids ambient electromagnetic interference, while IP68 waterproof capability ensures steady connection of field devices under changeable outdoor rainy, dusty and temperature-varying environments.
Serving as specialized onboard interconnect component for marine navigation locators, underwater detecting transducers, ship communication host and offshore environmental monitoring equipment, high pressure and salt fog resistant features guarantee uninterrupted power and signal transmission amid long-term seawater soaking and humid marine atmosphere.
It gets widely adopted in micro PLC, handheld precision testing instruments, robotic end actuators and industrial control sensors. Type-C high-speed transmission realizes rapid onsite data upload, and push-pull quick disconnect design facilitates frequent plug operation during factory routine overhaul and parameter calibration.
Applicable for outdoor smart city terminal units, UAV ground base stations and field emergency rescue hardware, wide temperature adaptability plus anti-vibration property safeguards normal equipment operation during extreme seasonal climate and long-distance transportation vibration.n.
Used in aviation emergency communication portable terminals and mini aerospace ground inspection instruments, excellent anti-interference and pressure-resistant performance satisfies aerospace industry strict reliability standards, and compact dimension simplifies field carrying and rapid assembly work.
Matched with underwater sonar detectors, subsea robot control assemblies, seabed observation apparatus and mariculture real-time monitoring sensors, 60bar pressure endurance and IP68 sealing enable long-term stable signal and power delivery in deep submergence working conditions.
A: Fitted with standard USB3.1 Type-C female core, the product supports high-speed data transmission and stable power supply, with rated working current fixed at 3A to complete synchronous integration of signal and power transmission for compact electronic products.
A: Relying on silicone washer sealing, epoxy resin internal encapsulation plus precise push-pull locking construction, the connector reaches IP68 after full mating; maximum withstand pressure is 60bar (870psi) to adapt deep-water high-pressure application.
A: 360-degree full EMC shielding restrains electromagnetic interference and signal leakage, ultra-flat structure saves limited inner equipment space, meanwhile IP68 waterproof and multi-environment resistance ensure steady running under complex outdoor field conditions.
A: Operating temperature ranges -55°C~125°C, equipped with anti-vibration, anti-shock and high-humidity resistance and passes 96-hour salt spray test, which supports long-term stable deployment within marine salt fog and damp
A: IIts rated mating life exceeds 5000 times above average industrial level; push-pull construction brings fast plugging, accurate positioning and anti-accidental disconnection, simplifying field operation and lifting whole-set equipment connection reliability.
